GM International Product Range:
D -1000 Series Intrinsically Safe Galvanic Isolators
DIN Rail Repeater Power Supply
DIN Rail Repeater Power Supply
Intrinsically Safe Switch/Proximity Detector
Intrinsically Safe Switch/Proximity Detector Repeater
Din Rail Digital Output Modules
D-2000 Series Intrinsically Safe Multiplexer
DTM-8000
PSD-1000 – Intrinsically Safe Power Supplies
Intrinsically Safe Wall Posters & SIL Posters

D -1000 Series Intrinsically Safe Galvanic Isolators

G.M. International DIN RAIL mounting Intrinsically Safe Galvanic Isolators and Repeaters. The D Range provides the most simple and cost effective means of implementing Intrinsic Safety into your Hazardous Areas/Locations applications.

2Download PDF

DIN Rail Repeater Power Supply

The D1014S and D1014D is a single and dual channel DIN Rail Repeater Power Supply requiring SIL 2 level (according to EN61508) in safety related system for high risk industries. Provides a fully floating dc supply for energizing conventional 2-wire 4-20 mA Transmitter or 3 / 4 Wire 4-20mA signals located in Hazardous Area, and repeats the current in floating circuit to drive a Safe Area load.

2Download PDF

DIN Rail Repeater Power Supply

The single and dual channel DIN Rail Repeater Power Supply, D1014S and D1014D is a high integrity analog input interface suitable for application requiring SIL 2 level (according to EN61508) in safety related system for high risk industries. Provides a fully floating dc supply for energizing conventional 2-wire 4-20 mA Transmitters located in Hazardous Area, and repeats the current in floating circuit to drive a Safe Area load.

2Download PDF

Intrinsically Safe Switch/Proximity Detector

D-1030 & D-1031 Series Intrinsically Safe Switch/Proximity Detector are a DIN Rail unit with one or two or four independent channels. The unit can be configured for contact or proximity detector, NO or NC and for NE or ND SPDT relay output contact.Each channel enables a Safe Area load to be controlled by a switch, or a proximity detector, located in Hazardous Area repeats the current in floating circuit to drive a Safe Area load.

2Download PDF

2Download PDF

2Download PDF



Intrinsically Safe Switch/Proximity Detector Repeater

D-1032D & D-1032Q SIL2 Series Intrinsically Safe Switch/Proximity Detector Repeater, is a DIN Rail unit with one or two or four independent channels. The unit can be configured for contact or proximity detector, NO or NC and for NE or ND SPDT relay output contact. Each channel enables a Safe Area load to be controlled by a switch, or a proximity detector, located in Hazardous Area repeats the current in floating circuit to drive a Safe Area load.

2Download PDF

Din Rail Digital Output Modules

The D1043 series are quad channel Din Rail Digital Output Modules enabling a Safe Area contact, logic level or drive signal, to control a Solenoid, Audible Alarm, or LED’s in Hazardous Area, providing 3 port isolation (input/output/supply).

2Download PDF

D-2000 Series Intrinsically Safe Multiplexer

D-2000 Series Intrinsically Safe MultiplexerThe use of an intrinsically safe multiplexer allows equipment installation in hazardous area and connection of all its inputs directly to the process variable signals

without the requirement of any further protection; retaining the simplicity and cost effectiveness of a multiplexing solution. In addition to the cable cost and simplicity of installation discussed above, the elimination of safety barriers drastically

simplifies and reduces the cost of this solution compared to other options.

2Download PDF

2Download PDF

DTM-8000

The DTM 8000 is a Continuous Smart Digital Alarm Monitor System used for the reliable and effective monitoring of up to 48 channels of process variables.

The system is not a multiplexing type machine, but a continuous one, which means there is no delay in monitoring the variables, because each input signal is continuously monitored in a parallel operating mode.

For this unique feature the unit is suitable to monitor critical rotating machines like Turbines and Compressors, (for instance: Bearing Temperature) where a few millisecond delay in alarming and shutting down could result in a disaster for the entire machine and plant operation.

2Download PDF

PSD-1000 – Intrinsically Safe Power Supplies

The PSD1000 is a DIN Rail mounting universal AC input switching power supply with 24 Vdc 500 mA current output capability, to supply D1000 Series units or other 24 Vdc devices; it provides isolation between input and output and a relay for detection of supply fault (input line, output overload or thermal overload). The output is protected from overload (current or thermal) and short circuit (the unit switches the output off for a second and then tries to re-activate it until the fault condition is removed).
The output is diode protected to connect multiple power supply (redundant output) or to increase the output power.

2 Download PDF

2Download PDF

2Download PDF

PSD-1000 – Intrinsically Safe Power Supplies

Understanding ATEX Hazardous Area Definitions

Understanding Safety Integrity Levels (SIL) Definitions
